CNC Machine Geometry Checks & Adjustments

CNC Machine Geometry Checks & Adjustments

Machine accuracy is critical to part quality. Over time, wear, movement, and crashes can affect machine geometry, leading to tolerance issues, poor surface finish, and scrap parts. We provide full CNC geometry inspections and precision adjustments to restore your machine’s accuracy to manufacturer standards.

Why Geometry Checks Are Important:

  • Maintain tight machining tolerances
  • Improve surface finish quality
  • Reduce scrap and rework
  • Prevent uneven wear on components
  • Restore machine performance after a crash
  • Ensure long-term accuracy

What We Check

  • Straightness and flatness
  • Squareness between axes
  • Parallelism checks
  • Backlash measurement

Spindle Alignment

  • Spindle runout testing
  • Spindle to table squareness
  • Taper condition inspection
  • Spindle bearing condition check

Machine Level & Base

  • Precision levelling of machine bed
  • Twist correction
  • Anchor point inspection
  • Foundation stability check

Rotary & 4th/5th Axis (if fitted)

  • Axis alignment
  • Centre line accuracy
  • Backlash and positioning repeatability
  • Rotary axis calibration check

What We Check

  • Straightness and flatness
  • Squareness between axes
  • Parallelism checks
  • Backlash measurement

Spindle Alignment

  • Spindle runout testing
  • Spindle to table squareness
  • Taper condition inspection
  • Spindle bearing condition check

Machine Level & Base

  • Precision levelling of machine bed
  • Twist correction
  • Anchor point inspection
  • Foundation stability check

Rotary & 4th/5th Axis (if fitted)

  • Axis alignment
  • Centre line accuracy
  • Backlash and positioning repeatability
  • Rotary axis calibration check
CNC Geometry Adjustment

Adjustment & Correction

We correct alignment, backlash, and geometry issues to restore machine accuracy and performance.

Where geometry errors are found, we:

  • Re-level and re-align the machine
  • Adjust gibs and guide systems
  • Correct backlash where possible
  • Reset machine parameters (if required)
  • Provide a detailed report of corrections made
CNC Machine Geometry Checks & Adjustments

When Should Geometry Be Checked?

Machine accuracy is critical to part quality. Over time, wear, movement, and crashes can affect machine geometry, leading to tolerance issues, poor surface finish, and scrap parts. We provide full CNC geometry inspections and precision adjustments to restore your machine’s accuracy to manufacturer standards.

  • After a machine crash
  • When parts are going out of tolerance
  • During annual servicing
  • After machine relocation
  • When excessive vibration is present

Don’t let machine downtime cost you money.

Call us today or request a service online to get your CNC machine back in production.
